Parts List - Linear Technology DC2490A Demo Manual

DEMO MANUAL DC2490A

parts List

ITEM QTY REFERENCE
Required Circuit Components
1 1 C1
2 1 C2
3 1 D1
4 1 D2
5 1 D3
6 1 D4
7 1 R1
8 1 R2
9 1 R3
10 1 T1
11 1 U1
Additional Demo Board Circuit Components
1 0 C3 (OPT)
2 0 C4 (OPT)
3 0 CIN (OPT)
Hardware: For Demo Board Only
1 4 E1 TO E4
4
Arrow.com. Arrow.com. Arrow.com. Arrow.com.
Downloaded from Downloaded from Downloaded from Downloaded from
PART DESCRIPTION
CAP , 4.7µF, X7S, 100V, 10% 1210
CAP , 220µF, X5R, 6.3V, 20% 1210
DIODE, SCHOTTKY, 30V, 3A, PowerDI123
DIODE, ZENER, 5.6V, 300mW, SOD-523
DIODE, ZENER, 62V, SOD-123
DIODE, 200V, SOD-123
RES, 402k, 1/10W, 1%, 0603
RES, 15.4k, 1/10W, 1% 0603
RES, 316k, 1/10W, 1%, 0603
TRANSFORMER, PS15-109
IC, LT8303ES5#PBF , TSOT23-5
CAP , OPT, 1210
CAP , OPT, 1808
CAP , 10µF, ALUM, 80V
TESTPOINT, TURRET, 0.094" PBF
MANUFACTURER/PART NUMBER
MURATA, GRJ32DC72A475KE11L
SAMSUNG, CL32A227MQVNNNE
DIODES INC, SBR3U30P1-7
DIODES INC, BZT52C5V6T-7
CENTRAL SEMI, CMHZ5265B
CENTRAL SEMI, CMMR1U-02
VISHAY, CRCW0603402KFKEA
VISHAY, CRCW060315K4FKEA
VISHAY, CRCW0603316KFKEA
SUMIDA, PS15-109
LINEAR TECHNOLOGY, LT8303ES5#PBF
MILL-MAX, 2501-2-00-80-00-00-07-0
dc2490af
