DEMO MANUAL DC2434A
parts List
ITEM
QTY
REFERENCE
Required Circuit Components
1
2
CIN1, CIN2
2
3
CIN3, CIN4, CIN5
3
2
COUT1, COUT2
4
1
COUT3
5
1
C3
6
1
C4
7
1
C5
8
1
C7
9
1
C8
10
1
C9
11
1
C10
12
1
D1
13
1
L1
14
1
Q1
15
1
R1
16
1
R2
17
1
R5
18
1
R7
19
1
R9
20
1
R10
21
1
R11
22
1
R12
23
1
R13
24
1
R14
25
1
U1
Additional Demo Board Circuit Components
1
0
C1
2
0
C2
3
0
D2
4
0
R6, R15
5
1
R4
Hardware: For Demo Board Only
1
8
E1, E2, E3, E4, E5, E6,
E7, E8
2
1
JP1
3
1
JP2
4
2
XJP1, XJP2
5
4
J1, J2, J3, J4
6
4
MTGS AT 4 CORNERS
4
PART DESCRIPTION
CAP ., ALUM, 22µF, 63V 6.3x7.7
CAP ., X7S, 4.7µF, 100V, 10%, 1210
CAP ., X7R, 10µF, 16V, 10%, 1206
CAP ., ALUM 56µF, 25V 6.3x5.8
CAP ., NPO, 1000pF, 50V, 10%, 0603
CAP ., X7R, 0.47µF, 16V, 10%, 0603
CAP ., X7R, 0.1µF, 100V, 10%, 0805
CAP ., X7R, 0.1µF, 50V, 10%, 0603
CAP ., COG, 3300pF, 50V, 5%, 0603
CAP ., COG, 330pF, 50V, 5%, 0603
CAP ., COG, 10pF, 50V, 5%, 0603
SCHOTTKY DIODE, 60V, 10A, DFN5-SO-8FL
INDUCTOR, 15µH
FET, P-CHAN., 100V, PowerPak SO-8
RES., 100kΩ, 1/8W, 1%, 0805
RES., 21.5kΩ, 1/10W, 1%, 0603
RES., 100Ω, 1/10W, 1%, 0603
RES., 13mΩ, 1W, 1%, 0612
RES., 37.4kΩ, 1/10W, 1%, 0603
RES., 10kΩ, 1/10W, 1%, 0603
RES., 464kΩ, 1/10W, 1%, 0603
RES., 33.2kΩ, 1/10W, 1%, 0603
RES., 1.0kΩ, 1/10W, 1%, 0603
RES., 100kΩ, 1/10W, 1%, 0603
IC, LTC3864EMSE MSE12
CAP ., OPT 0603
CAP ., OPT 0805
SCHOTTKY DIODE, OPT, SOD323
RES., OPT, 0603
RES., 0Ω, 1/16W, 0603
TESTPOINT, TURRET, .094"
CONN., HEADER, 1X3, 2mm
CONN., HEADER, 2X3, 2mm
SHUNT, 2mm
CONN, BANANA JACK,
STAND-OFF , SNAP ON NYLON 0.50" tall
MANUFACTURER/PART NUMBER
PANASONIC, EEHZA1J220XP
MURATA, GRM32DC72A475KE01
MURATA, GRM31CR71C106KA12
PANASONIC, EEHZA1E560P
AVX, 06035A102KAT2A
MURATA, GCM188R71C474KA55L
MURATA, GRM21BR72A104KAC4
MURATA, GCM188R71H104KA57D
MURATA, GCM1885C1H332JA16D
MURATA, GCM1885C1H331JA16D
MURATA, GCM1885C1H100JA16D
ON SEMI, NRVB860MFST1G
COILCRAFT, XAL1510-153
FAIRCHILD, FDMS86163P
VISHAY, CRCW0805100KFKEA
VISHAY, CRCW060321K5FKEA
VISHAY, CRCW0603100RFKEA
PANASONIC, ERJ-B2CFR013V
VISHAY, CRCW060337K4FKEA
VISHAY, CRCW060310K0FKEA
VISHAY, CRCW0603464KFKEA
VISHAY, CRCW060333K2FKEA
VISHAY, CRCW06031K00FKEA
VISHAY, CRCW0603100KFKEA
LINEAR TECH.CORP . LTC3864EMSE#PBF
OPT
OPT
OPT
OPT
VISHAY, CRCW06030000Z0EA
MILL MAX, 2501-2-00-80-00-00-07-0
WURTH ELEKTRONIK, 62000311121
WURTH ELEKTRONIK, 62000621121
WURTH ELEKTRONIK, 60800213421
KEYSTONE 575-4
KEYSTONE, 8833
dc2434af
