DEMO MANUAL DC2056A

PARTS LIST

ITEM QTY
Required Circuit Components
1 1
2 1
3 1
4 1
5 2
6 1
7 1
8 1
9 1
10 1
11 2
12 1
Additional Demo Board Circuit Components
1 0
2 0
Hardware
1 5
2 3
3 3
6
Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.
Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from
REFERENCE PART DESCRIPTION
C1 CAP, 47µF 20% 100V ALUM
C2 CAP, 2220 4.7µF 20% 100V X7R
C3 CAP, 0603 47pF 5% 50V C0G
C4 CAP, 0603 47nF 10% 25V X7R
C6, C7 CAP, 1210 100µF 20% 10V X5R
C9 CAP, 0603 0.1µF 10% 25V X7R
D1 DIODE, SUPER BARRIER RECTIFIER
L1 IND, 10µH 30% 4.45A SMD
R1 RES, 0603 1M 5% 1/10W
R4 RES, 0603 255k 1% 1/10W
R5, R6 RES, 0603 0Ω JUMPER
U1 IC, HIGH EFFICIENCY STEP-DOWN CONVERTER
C8, C10, C11 CAP, 1210 OPTION
R2, R3, R7 RES, 0603 OPTION
E1, E2, E3, E4, E5 TURRET
JP1, JP2, JP3 HEADER, 3-PIN, 2mm
JP1, JP2, JP3 SHUNT, 2mm
MANUFACTURER/PART NUMBER
NIPPON CHEMI-CON EMVY101ARA470MKE0S
TDK C5750X7R2A475M
AVX 06035A470JAT2
AVX 06033C473KAT
MURATA GRM32ER61A107ME20L
AVX 06033C104KAT2A
DIODES INC. SBR3U100LP
SUMIDA CDRH105RNP-100NC
NIC NRC06J105TRF
VISHAY CRCW0603255KFKEA
VISHAY CRCW06030000Z0EA
LINEAR TECH. LTC3637EMSE
OPTION
OPTION
MILL MAX 2501-2-00-80-00-00-07-0
SAMTEC TMM-103-02-L-S
SAMTEC 2SN-BK-G
dc2056af
