DEMO MANUAL DC2372A

parts List

ITEM QTY REFERENCE
1 1 C1
2 1 C2
3 1 C3
4 0 C4
5 1 C5
6 1 C7
7 1 C8
8 1 C9
9 6 E1-E6
10 2 JP2, JP1
11 2 XJP1, XJP2
12 1 L1
13 1 R1
14 1 R2
15 0 R3
16 1 R4
17 1 R5
18 1 R6
19 1 U1
20 4 STAND OFF
21 1
22 2
4
PART DESCRIPTION
CAP 10μF X5R 10V 10%1206
CAP 0.10μF X7R 50V 10% 0603
CAP 4.7μF X5R 25V 10% 0805
CAP 0402 OPT
CAP 22μF 25V X5R 10% 1210
CAP 1μF X7R 25V 10% 0603
CAP 1nF 50V X7R 10% 0402
CAP 10pF C0G 25V 5% 0402
TEST POINT, TURRET, 0.094 MTG. HOLE
CONN, HEADER, 1 × 3, 2mm
SHUNT, 2mm
IND, PWR 6.8μH, 20%, XAL40xx Series
RES, 1MΩ 1/10W 1% 0402
RES, 57.6kΩ 1/10W 1% 0402
RES,0402 OPT
RES 1.02MΩ 1/10W 1% 0402
RES, 113kΩ 1/10W 1% 0402
RES, 82.5kΩ 1/10W 1% 0402
IC, LTC3121EDE
STAND-OFF, NYLON 0.500"
FAB, PRINTED CIRCUIT BOARD
STENCILS, TOP & BOTTOM
MANUFACTURER/PART NUMBER
TDK, C3216X5R1A106K
TDK, CGA3E2X7R1H104K080AA
TDK,C2012X5R1E475K085AC
OPT
MURATA, GRM32ER61E226KE15L
TDK, CGA3E1X7R1E105K080AC
AVX, 04025C102KAT2A
AVX, 04023A100JAT2A
MILL-MAX, 2501-2-00-80-00-00-07-0
SAMTEC, TMM-103-02-L-S
SAMTEC, 2SN-BK-G
COILCRAFT, XAL4030-682ME
PANASONIC, ERJ2RKF1004X
PANASONIC, ERJ2RKF5762X
OPT
VISHAY, CRCW04021M02FKED
PANASONIC, ERJ2RKF1133X
PANASONIC, ERJ2RKF8252X
LINEAR TECH, LTC3121EDE
KEYSTONE, 8832 (SNAP ON)
LINEAR TECH, DEMO CIRCUIT 2372A
LINEAR TECH, DEMO CIRCUIT 2372A
dc2372af
