DEMO MANUAL DC1883A

parts List

ITEM QTY REFERENCE
Required Circuit Components
1 1 C1
2 3 C2, C4, C6
3 1 C3
4 1 C7
5 1 C8
6 1 L1
7 1 R1
8 1 R2
9 4 R3, R4, R5, R6
10 1 U1
Additional Demo Board Circuit Components
1 0 C5 (OPT)
2 0 C9 (OPT)
3 0 R9
Hardware—for Demo Board Only
1 5 E1, E2, E3, E4, E5
2 2 JP1, JP2
3 2 XJP1, XJP2
4 4 (Stand-Offs)
4
Arrow.com. Arrow.com. Arrow.com. Arrow.com.
Downloaded from Downloaded from Downloaded from Downloaded from
PART DESCRIPTION
CAP CER, 10µF , 25V, X5R, 1210
CAP CER, 1µF , 25V, X5R, 0603
CAP CER, 22µF , 10V, X5R, 20%, 1206
CAP CER, 12pF , 50V, C0G 5%, 0603
CAP CER, 0.1µF , 50V, X7R, 0603
Inductor, 15µH
RES, 2MΩ, 1/10W, 1%, 0402, SMD
RES, 2.21kΩ, 1/10W, 1%, 0402, SMD
RES, 1MΩ, 1/10W, 1%, 0402, SMD
LTC3103EDD
CAP CER, 1000pF , 50V, X7R, 20%, 0603
OPT CAP TANT, 68µF , 20V, 10%, SMD, 7343
OPT RES, 1/10W, 1%, 0402, SMD
Testpoint, Turret 0.094"
JMP , 0.079" Single Row Header, 30-Pin
Shunt, 0.079" Center
Stand-Off, Nylon, 0.375" Tall
MANUFACTURER/PART NUMBER
TDK, C3225X5R1E106M
TDK, C1608X5R1E105M
TDK, C3216X5R1A226M
TDK, C1608C0G1H120J
TDK, C1608X7R1H104M
Coilcraft, LPS4018-153MLB
Panasonic, ERJ-2GEJ205X
Panasonic, ERJ-2RKF2211X
Panasonic, ERJ2RKF1004X
Linear Technology Corporation, LTC3103EDD
OPT
OPT
OPT
Mill-Max, 2501-2-00-80-00-00-07-0
Samtec, TMM-103-02-L-S
Samtec, 2SN-BK-G
Keystone, 8832 (Snap on)
