Holtek HT66F60A Manual page 91

HT66F60A/HT66F70A
A/D Flash MCU with EEPROM
• IFS1
Bit 7
Name TCK3S1
R/W R/W
POR 0
Bit 7~6 TCK3S1~TCK3S0: TCK3 input source pin selection
00: PC4
Others: PE3
Bit 5~4 TCK2S1~TCK2S0: TCK2 input source pin selection
00: PC2
Others: PD0
Bit 3~2 TCK1S1~TCK1S0: TCK1 input source pin selection
00: PA4
Others: PD3
Bit 1~0 TCK0S1~TCK0S0: TCK0 input source pin selection
00: PH1
Others: PD2
• IFS2
Bit 7
Name TP�IS1
R/W R/W
POR 0
Bit 7~6 TP2IS1~TP2IS0: TP2I input source pin selection
00: PC3
01: PC4
10: PD1
11: PD4
Bit 5~4 TP1IBS1~TP1IBS0: TP1IB input source pin selection
00: PC0
01: PC1
10: PC5
11: PE4
Bit 3~2 TP1IAS1~TP1IAS0: TP1IA input source pin selection
00: PA1
Others: PC7
Bit 1~0 Reserved bits, can be read and written.
• IFS3
Bit 7
Name D�
R/W R/W
POR 0
Bit 7~6 Reserved bits, can be read and written.
Bit 5~4 TP5IS1~TP5IS0: TP5I input source pin selection
00: PG6
Others: PG7
Bit 3~2 TP4IS1~TP4IS0: TP4I input source pin selection
00: PG3
Others: PG4
Bit 1~0 Reserved bits, can be read and written.
Rev. 1.40
6 5 4
TCK3S0 TCK�S1 TCK�S0
R/W R/W R/W
0 0 0
6 5 4
TP�IS0 TP1IBS1 TP1IBS0 TP1I�S1 TP1I�S0
R/W R/W R/W
0 0 0
6 5 4
D6 TP5IS1 TP5IS0
R/W R/W R/W
0 0 0
91
3 2 1
TCK1S1 TCK1S0 TCK0S1
R/W R/W R/W
0 0 0
3 2 1
D1
R/W R/W R/W
0 0 0
3 2 1
TP4IS1 TP4IS0 D1
R/W R/W R/W
0 0 0
����st ��� �01�
0
TCK0S0
R/W
0
0
D0
R/W
0
0
D0
R/W
0
