Lockly LATCH EDITION SECURE PGD628 Installation Manual page 7

1 " - 2"
(35mm - 50mm)
*
1"
25mm
IMPORTANT NOTICE
* You are not required to drill an extra hole on your door. We have provided double
sided Adhesive tape for you to help stabilize the lock during installation. Only drill a hole
if you wish to have added stability. Please refer to the provided template for drilling if
needed.
1.3
Measure and confirm your door is
between 1
1.4
Measure and confirm the hole in the
door is 2
1.5
2 "
Measure and confirm that the backset
54mm
is between 2
1.6
Backset
Measure and confirm that hole in the
2 " (60mm)
door edge is 1" (25mm).
or 2 " (70mm)
" - 2" ( 35mm - 50mm).
" (54mm).
" (60mm) to 2 " (70mm).
