Lockly LATCH EDITION SECURE PGD628 Installation Manual page 15

STEP 6: INSTALLING THE LOCK (INTERIOR)
Interior
V
Mounting Plate (LK)
Positioning rods slide through these holes.
6.1
Insert Positioning Rods (V) into
the holes to the left and
right of the Spindle (C).
The holes are located at the 3
o'clock and 9 o'clock positions.
6.2
Interior Mounting Plate (LK) will go
against the interior side of your door.
Remove the paper layer off of the
Adhesive Tape and align the
positioning rods on the bottom of
the plate to the corresponding left
and right holes.
Install the side with the black
plastic seal against the door.
