No. Cable Port or Expansion Slot
5 Network management port (NET MGT)
6 Serial management port (SER MGT)
Related Information
"Ethernet Ports" on page 63
■
"Connect the Power Cords" on page 64
■

Ethernet Ports

The storage server has four RJ-45 10-Gigabit Ethernet (10GbE) network connectors, labeled
NET 3, NET 2, NET 1, and NET 0, from left to right on the storage server rear panel. Use these
ports to connect the storage server to the network.
The LEDs located above each NET port are Link/Activity (left) and Speed (right) indicators for
each port. The following table lists the Ethernet transfer rates and the Speed LED color.
Connection Type
Fast Ethernet
Gigabit Ethernet
10 Gigabit Ethernet
Related Information
"Rear Cable Connections and Ports" on page 61
■
"Connect the Power Cords" on page 64
■
Description
The service processor NET MGT port is the optional connection to the
Oracle ILOM service processor. The NET MGT port is configured by default
to use Dynamic Host Configuration Protocol (DHCP). The service processor
NET MGT port uses an RJ-45 cable for a 10/100/1000BASE-T connection.
The service processor SER MGT port uses an RJ-45 cable and is the default
connection to the Oracle ILOM service processor. This port supports
local connections to the storage server and only recognizes Oracle ILOM
command-line interface (CLI) commands. Typically you connect a terminal
or terminal emulator to this port.
Note - This port does not support network connections.
IEEE Terminology Speed LED Color
100BASE-TX Off
1000BASE-T Amber
10GBASE-T Green
Ethernet Ports
Transfer Rate
100 Mbits/sec
1,000 Mbits/sec
10,000 Mbits/sec
Cabling the Storage Server 63
