Front Panel Status Indicators, Connectors, and Drives

The following figure shows the status indicators (LEDs), connectors, and drives on the front

panel of a Oracle Exadata Storage Server X5-2 Extreme Flash configured with twelve 2.5-inch

storage drives.

Call Out

Description

■ Support for remote KVMS (keyboard, video, mouse, and storage) over IP

Two hot-swappable and redundant 1000W power supplies.

Four 80-mm, hot-swappable fan modules. Each fan module contains two counter-

rotating fan pairs. Each power supply has its own cooling fans.

Exadata preinstalled operating system (OS) image located on NVMe drives 0, 1.

Description

Locator LED/Locator button: white

Service Required LED: amber

Power/OK LED: green

Power button

Front Panel Status Indicators, Connectors, and Drives
