Gently tug on the right side of the front slide bar to verify that connector A is

properly seated.

Callout

To install the CMA's connector B into the right slide-rail:

Insert the CMA's connector B into the front slot on the right slide-rail until it

locks into place with an audible click [frames 1 and 2].

The connector B tab (callout 1) goes into the slide-rail's front slot (callout 2).

Description

Connector A tab

Left slide-rail front slot

Installing the Storage Server Into a Rack

Install the Cable Management Arm
