The following figure shows the CMA components.
Callout
1
2
3
4
5
6
7
8
Description
Connector A
Front slide bar
Velcro straps (6)
Connector B
Connector C
Connector D
Slide-rail latching bracket
(used with connector D)
Rear slide bar
Install the Cable Management Arm
Installing the Storage Server Into a Rack
41
