- Page 1 4K HDR HDMI 2.0 18G Extender 50M over Cat6 All Right Reserved MPN: EXT-USB250M VER. 1.0...
-
Page 2: Table Of Contents
SAFETY PRECAUTIONS Please read all instructions before attempting to unpack, install or operate this equipment and before connecting the power supply. Please keep the following in mind as you unpack and install this equipment: • Always follow basic safety precautions to reduce the risk of fire, electrical shock and injury to persons. -
Page 3: Introduction
1. Introduction The KanexPro EXT-50M18G extender is a set of transmitter and receiver which sends full UHD 4K/60 HDMI signals over CAT6 cable up to 164ft. (50m). The transmitter module features a local HDMI output for preview monitor or local display support enabling you to see what you are extending over CATx cable. -
Page 4: Specifications
4. Specifications Technical HDMI Compliance HDMI 2.0 HDCP Compliance HDCP 2.2 / HDCP 1.4 Video Bandwidth 18Gbps Video Resolution Up to 4K60Hz 4:4:4 Color Space RGB / YCbCr 4:4:4, YCbCr 4:2:2/4:2:0, YUV 4:4:4 Color Depth 8/10/12-bit (1080P60Hz, 4K30Hz, 4K60Hz YCbCr 4:2:2/4:2:0) 8-bit (4K60Hz 4:4:4 ) HDMI Audio Formats... -
Page 5: Operation Controls And Functions
5. Operation Controls and Functions 5.1 Transmitter Panel Numb Name Function description HDMI OUT HDMI loop output port, connect to HDMI display device such as TV or Projector with an HDMI cable. HDMI IN HDMI input port, connect to HDMI source device such as DVD or PS4 player with an HDMI cable. -
Page 6: Ir Pin Definition
Number Name Function description HDMI OUT HDMI output port, connect to HDMI display device such as TV or Projector with an HDMI cable. CAT IN Connect to CAT OUT port on the transmitter end with a CAT6 cable. Power The lamp will illuminate when the receiver is Indicator powered on. -
Page 7: Application Example
The following is IR system diagram about IR cable use method. 6. Application Example... -
Page 8: Customer Service
7. Customer Service The return of a product to our Customer Service implies the full agreement of the terms and conditions hereinafter. There terms and conditions may be changed without prior notice. ① Warranty The limited warranty period of the product is fixed 3 (three) years. ②...
