Summary of Contents for SIIG AV-GM02J3-S1
- Page 1 HDMI over Coaxial Extender with Bi-directional IR Pass-through P/N: AV-GM02J3-S1...
-
Page 2: Table Of Contents
However, like all electronic equipments, the AV-GM02J3-S1 should be used with care. Please read and follow the safety instructions to protect yourself from possible injury and to minimize the risk of damage to the unit. -
Page 3: Introduction
HDMI over Coaxial Extender with Bi-directional IR Pass-through boosts up your HDMI transmission range up to 100m (330ft) in HDTV 1080p format. AV-GM02J3-S1 is easy to install and works perfectly with the RGBHV or RG-6 coaxial cables. Coaxial cables are typically used for VGA or component signals, and provide the audio/video professionals with remarkable flexibility. -
Page 4: Specifications
● 1x User Manual SPECIFICATIONS Model Name AV-GM02J3-S1 Technical AV-GM02J3-S1[Tx] AV-GM02J3-S1[Rx] Role of usage Transmitter [TX] Receiver [RX] HDMI compliance HDMI Deep Color HDCP compliance Video bandwidth Single-link 340MHz [10.2Gbps] 480i / 480p / 720p / 1080i / 1080p60 / 1920x1200@75 / 2560x1600@60... -
Page 5: Panel Descriptions
PANEL DESCRIPTIONS Transmitting unit ► AV-GM02J3-S1-TX Front Panel 1. IR Flasher: 3.5mm socket for plugging in the extension cable of IR flasher 2. IR Receiver: 3.5mm socket for plugging in the extension cable of IR receiver 3. HDMI IN: connect to a HDMI source device with a HDMI male-male cable 4. -
Page 6: Receiving Unit ► Rx
Receiving unit ► AV-GM02J3-S1-RX Front Panel 8. IR Flasher: 3.5mm socket for plugging in the extension cable of IR flasher 9. IR Receiver: 3.5mm socket for plugging in the extension cable of IR receiver 10. HDMI OUT: connect to a HDMI display with a HDMI male-male cable 11. -
Page 7: Ir Pass-Through
IR PASS-THROUGH IR Extenders IR Blaster IR Receiver IR Sockets IR BLASTER: plug in the IR blaster to emit all IR command signals received from the IR receiver from the other enf to control the devices corresponding to the IR signals. IR RECEIVER: plug in the IR receiver to receive all IR command signals from the IR remote controls of the corresponding devices. -
Page 8: Hdmi Pin Definition
HDMI PIN DEFINITION Type A (Receptacle) HDMI Pin 1 TMDS Data2+ Pin 11 TMDS Clock Shield Pin 2 TMDS Data2 Shield Pin 12 TMDS Clock– Pin 3 TMDS Data2– Pin 13 Pin 4 TMDS Data1+ Pin 14 Reserved (N.C. on device) Pin 5 TMDS Data1 Shield Pin 15... -
Page 9: Notice
NOTICE 1. Incorrect placement of IR Blaster and Receiver may result in the failure of the IR extenders. Please check carefully before plugging in the IR extender to the respective IR sockets. Warranty will not cover the damage. 2. All HDMI transmission distances are measured using Belden 7789A coaxial cables and ASTRODESIGN Video Signal Generator VG-859C &... -
Page 10: Warranty
The SELLER will NOT be liable for direct, indirect, incidental, special, or consequential damages resulting from any defect or omission in this manual, even if advised of the possibility of such damages. Also, the technical information contained herein regarding the AV-GM02J3-S1 features and specifications is subject to change without further notice.
