The DIVI vendor leaves the factory pre-wired with a DEX port located inside the door near the left side of the window frame. To collect
sales data using the DEX port, insert the plug from your DEX handheld into the port and pull out the pin on the 3 position
service/door/interlock switch. The door switch is located below the threads of the T-Handle bolt on the back of the door. It is
necessary for the machine to have a unique identification number entered into the serial number field on the Service Menu Option 17)
Machine Serial Number (defaults to the VMC Board serial number). Your DEX interrogator may need to be initialized prior to the first
read to allow the vendor to be recognized.
Installing Peripherals
Coin and bill accepters as well as card readers and other MDB peripherals should be installed and their function tested prior
to placing the vendor into service. Always turn OFF the Power Supply rocker switch (bottom of door under Delivery Bin)
before plugging or unplugging MDB peripherals. Hot plugging MDB devices will result in a blown control board.
Coin Mechanism/Changer
The Coin Changer mounts onto (3) screws on the back of the door inside the security door. Make
sure that all (3) mounting screws are tightened. The coin changer harness can be plugged directly
into the MDB harness (VMC location J8 MDB) or it can be plugged into the Bill Acceptor Y-Harness.
Fill all coin tubes until a coin from each tube overflows into the cash box. Test the operation of the
coin changer after filling the tubes.
If the display reads, "Machine Must Be Set Up",
the coin changer for proper operation.
While testing, push the coin return to verify that coins will dispense into the coin return cup.
Coins may be dispensed by pressing the payout keys on Service Keypad or by going to Service Menu
Option 18) Fill / Dispense.
Bill Acceptor
Remove the lower block-off plate from the door by removing the four #8 nuts with an 11/32" socket
wrench. Install the Bill Acceptor onto the studs using the four #8 nuts that had previously held on the
block-off plate. Some bill validators may require the use of stud extensions. These are usually
supplied with the bill validator and should be used only if necessary. Tighten all four nuts to secure
the assembly, then turn ON the vendor and test for proper operation.
Card Readers and Telemetry Systems
There are many card readers and telemetry systems available. Fastcorp has tested many of these
devices to insure compatibility with our software. On occasion, a new product will be introduced
which may require further testing to insure compatibility. If you have any questions relating to your
MDB peripherals, please call Fastcorp Technical Service.
Card Readers may be installed directly above the Customer Keypad. Remove the upper block-off
plate and install on the four available studs using the four block-off plate #8 retainer nuts and an
11/32" socket wrench.
