5.

FAMILIARIZE YOURSELF WITH THE NEW ROBOT

3
2
1
6.

TRANSPORT, UNPACKING AND INITIAL SETUP INSTRUCTIONS

DIVI
The Vendor should always be maintained in an upright position. Failure to do so may result in permanent damage to the
vendor. Whenever the
Replace cable ties as necessary. Refer to the uncrating instructions for cable tie and shipping bracket installation.
!! ATTENTION!!
ALL SHIPPING BRACKETS MUST BE REMOVED BEFORE APPLYING POWER TO THE MACHINE. FAILURE TO DO SO MAY RESULT IN
PERMANENT DAMAGE TO THE ROBOT OR ELECTRONICS.
DIVI Setup and Users Guide
2300014
1
F003-A04168
2
F003-A03910
3
8018132001
4
F003-A04171
5
F003-A04147
6
7
A. TRANSPORT CONSIDERATIONS
DIVI
Vendor is transported, always install the shipping brackets that were provided with the machine.
Fastcorp, LLC
4
5
6
Robot Arm Assembly
Vac Cup (AKA picker tip)
Weighted Picker Assy
Forearm Assy - with Cover Assy 1100354
Vacuum Hose
Vac Hose Drive Assy
Humerus Assy - with cover assy 1100354
Robot Shoulder Cover
Page 13 of 62
7
Rev 6
