3
3.2 standards & regulatIons - Flue systeMs
FIREBIRD BALANCED FLUE SYSTEMS
Vertical balanced flue kit - max. flue length 6m.
Low level balanced flue kit - max. length 3m.
High level balanced flue kit - max. length 6m.
Overall length must take into account bends
where 45° bend = 0.5m length and
90° bend = 1m length.
Elbows: 45°, 90°
Adjustable extensions:
305-420mm, 555-920mm
Extensions: 250mm, 500mm, 1000mm
INSTALLATION INSTRUCTIONS SUPPLIED WITH ALL FLUE KITS
8
