4.3 systeM BoIler - teCHnICal detaIls
No.
Qty
Description
1
1
Deflector baffle
2
1
Base baffle
3
3
Smoke baffle
4
1
Door gasket
5
1
Ceraboard door
6
1
Gasket seal
7
1
Stat pocket
8
1
Flue elbow adaptor
9
1
Bolt M8X150
10
1
Air hose
11
1
Control panel
12
1
Casing left side
13
1
Casing side cover
14
1
Casing right side
15
1
Casing top support
16
1
Casing front
17
2
Side flue blank
18
1
Casing top
19
1
Top flue blank
20
1
Casing back
21
1
Expansion vessel 12 litre
22
1
Pressure vessel
For burner parts refer to burner manual
10
11
14
16
5
4
21
3
2
SySTEM 120 - 35kW BOIlER
Sales Code
210049
210050
210060
113016
112368
110555
ACC003PKT
210249
110437
ACC000SSH
314734
214744
214748
214745
214749
214746
114729 + 114730 + 114731
214750
114728 + 114729 + 114730
214747
ACC012PVL
ACC012PVL
18
17
7
9
1
19
19
15
8
6
20
17
12
13
