4.3 systeM BoIler - teCHnICal detaIls
No.
Qty
Description
1
4
Smoke baffle
2
1
Door gasket
3
1
Door duroboard
4
1
Bolt M8X150
5
1
Flue elbow adaptor
6
1
Gasket seal
7
1
Stat pocket
8
1
Air hose
9
1
Control panel
10
1
Casing left side
11
1
Casing side cover
12
1
Casing right side
13
1
Casing top support
14
1
Casing front
15
2
Side flue blank
16
1
Casing top
17
1
Top flue blank
18
1
Casing back
19
1
Expansion vessel 12 litre
For burner parts refer to burner manual
8
9
12
14
19
3
2
1
SySTEM 90 - 26kW BOIlER
Sales Code
210015
113015
210017
110437
210249
110555
ACC003PKT
ACC000SSH
314734
214744
214748
214745
214749
214746
114729 + 114730 + 114731
214750
114728 + 114729 + 114730
214747
ACC012PVL
18
16
15
7
4
17
13
5
6
18
15
10
11
