Command access MLRK1 Series Insert Instructions page 5

7. Now with the motor kit installed slide the push pad
back into the exit device housing.
9.
Secure the motor kit to the base rail with the (4)
provided screws.
Select your preferred torque mode (ships in standard torque). Press the device push pad
Step 1-
to the desired setting (Recommend to fully depress and release 5%, giving the device
room for changing door conditions).
While depressing the push pad, apply power (i.e. presenting the credential to the reader).
Step 2-
Continue to keep pad depressed, the device will beep 6 times. After the beeps have
Step 3-
stopped, release the pad and now the adjustment is complete. If not to your liking repeat
the three steps.
Step 4-
Once you found the correct location, flip the dip switches to off to lock programming.
U S c u s t o m e r s u p p o r t 1 - 8 8 8 - 6 2 2 - 2 3 7 7 | w w w . c o m m a n d a c c e s s . c o m | C A c u s t o m e r s u p p o r t 1 - 8 5 5 - 8 2 3 - 3 0 0 2
Installation Instructions
Setting PTS
8. Make sure to route power wires over the back
activating bracket.
10.
Flip the device over & set the PTS by following the
steps below, remembering to turn the Programming
Switch to the off position when completed.
MM4 SWITCHES
OFF
1 STANDARD TORQUE
ON
HIGH TORQUE
ON
2 PTS PROGRAMMING ON
OFF
PTS PROGRAMMING OFF
# 2 0 4 2 3 _ B
