Port 2 L/A (OUT)

Green

Information

Link activity on port 2

Blinking Data transfer on port 2

OFF

Port closed

Fig. 31: LED status, part 3

5.3 Topologies and downstream devices

EtherCAT

supports flexible topologies when building a network.

For example, line, star, ring and tree structures are possible. The

two ports of the R-Series V EtherCAT

inside the sensor. Therefore, a power failure of the sensor leads to the

interruption of communication to the devices connected behind it. This

can be avoided, for example, by extending a line structure to a ring

structure.

MS/ER

NS/RN

are coupled with each other

I 25 I

R-Series V EtherCAT

Temposonics

Operation Manual
