2.2 Rear

2.2 Rear
1
Warning symbols
(see chapter 1.5.4, page 5)
3 Stirrer connector
For propeller stirrer (802 Stirrer) and mag-
netic stirrer (741 Magnetic Stirrer)
5 Connector strip
Details (see chapter 2.3, page 9)
￭￭￭￭￭￭￭￭
8
Figure 2 Rear 919 IC Autosampler plus
2
Pump connectors
M8 connector for external pumps
4 786 Swing Head connector
￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭
1
2
3
4
5
919 IC Autosampler plus
