3.8 Connecting MSB devices
￭￭￭￭￭￭￭￭
22
Stirrer / Ti Stand
Remote Box
Relay Box
Dosino
Figure 12 MSB connections
The control instrument determines which peripheral devices are suppor-
ted.
NOTICE
When connecting MSB devices together, the following must be
observed:
Only one device of the same type can be used at a single MSB con-
￭
nector at one time.
The MagIC Net software supports only dosing devices of the 800
￭
Dosino type.
CAUTION
Exit the control software before you plug in MSB devices. When it is
switched on, the control instrument automatically recognizes which
device is connected to which MSB connector. The operating unit or the
control software enters the connected MSB devices into the system
configuration (device manager).
MSB connections can be extended with the 6.2151.010 cable. The maxi-
mum connection length permitted is 15 m.
￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭
MSB
Ti Stand / Stirrer
Dosino
919 IC Autosampler plus
Dosino
