DEMO MANUAL DC1392A

PARTS LIST

ITEM QTY REFERENCE
Required Circuit Components
1 2 C1, CO5
2 2 CIN1, CIN2
3 1 CO3
4 1 R5
5 1 R2
6 1 U1
Additional Demo Board Circuit Components
1 0 C2 (OPT)
2 1 C3
3 0 CO1, CO2 (OPT)
4 0 CO4 (OPT)
5 0 CSS, CP , CFF (OPT)
6 1 Q1
7 1 R1
8 1 R3
9 1 R4
10 1 R6
11 1 R7
12 1 R8
13 1 R9
14 0 R10-R12 (OPT)
Hardware–For Demo Board Only
1 2 J1, J2
2 5 JP1-JP5
3 2 JP6, JP7
4 3 JP1, JP6, JP7
5 10 TP1, TP4-TP9, TP12, TP14, TP15
6 4 TP2, TP3, TP10, TP11
7 4 STAND OFF
4
Arrow.com. Arrow.com. Arrow.com. Arrow.com.
Downloaded from Downloaded from Downloaded from Downloaded from
PART DESCRIPTION
CAP ., X5R, 100μF , 6.3V, 20%, 1812
CAP ., X5R, 10μF , 6.3V, 10%, 1206
CAP ., X5R, 22μF , 6.3V, 10%, 1206
RES., CHIP , 10k, 1/16W, 1%, 0603
RES., CHIP , 510k, 1/16W, 5%, 0603
I.C., LTM4604AEV
CAP ., 0603
CAP ., X5R, 4.7μF , 6.3V, 10%, 0603
CAP ., 1210
CAP ., 1812
CAP ., 0603
N-CHANNEL 30V MOSFET, TO-252
RES., CHIP , 100K, 1/16W, 5% ,0603
RES., CHIP , 10K, 1/16W, 1%, 0603
RES., CHIP , 0.01Ω, 0.5W, 1% ,1206
RES., CHIP 5.76k, 1/16W, 1%, 0603
RES., CHIP 4.02k, 1/16W, 1%, 0603
RES., CHIP , 2.37k, 1/16W, 1%, 0603
RES., CHIP , 1.58k, 1/16W, 1%, 0603
RES., 0603
CONN, BNC, 5-PINS
2MM SINGLE ROW HEADER, 2-PIN
2MM SINGLE ROW HEADER, 3-PIN
SHUNT
TESTPOINT, TURRET, 0.095"
BANANA JACK
STAND-OFF , NYLON 0.50" TALL
MANUFACTURER/PART NUMBER
TDK, C4532X5R0J107M
AVX, 12066D106KAT2A
AVX, 12066D226KAT2A
VISHAY, CRCW060310K0FKEA
VISHAY, CRCW0603510KJNEA
LINEAR TECH., LTM4604AEV#PBF
AVX, 06036D475KAT2A
VISHAY, SUD50N03-10CP-E3
VISHAY, CRCW0603100KJNEA
VISHAY, CRCW060310K0FKEA
VISHAY, WSL1206R0100FEA18
VISHAY, CRCW06035K76FKEA
VISHAY, CRCW06034K02FKEA
VISHAY, CRCW06032K37FKEA
VISHAY, CRCW06031K58FKEA
CONNEX, 112404
SAMTEC, TMM-102-02-L-S
SAMTEC, TMM-103-02-L-S
SAMTEC, 2SN-BK-G
MILL-MAX, 2501-2-00-80-00-00-07-0
KEYSTONE, 575-4
KEYSTONE, 8833 (SNAP ON)
