Radiation interference occurs when energy (usually radio frequency energy) is emitted from a device and propagated
through space to disrupt other devices. The interference source can be part of disrupted system or a fully electrically
isolated unit. Conduction interference occurs when interference is transferred from one unit to another through cables,
which are usually electromagnetic wires or signal cables connected between the source and the device(s) experiencing
interference. Conduction interference often affects the power supply of the device. It is eliminated by using filters.
Radiation interference can influence the path of any signal from the device and is difficult to shield.

Take effective measures against interference from the power grid.

Keep the AP far away from the grounding or lightning protection devices for power equipment.

Keep the AP away from high-power radio stations, radar stations, and high-frequency high-current devices.

Take electrostatic shielding measures.

2.3 Fiber Connection

Before connecting fiber cables, make sure the model of the optical transceiver and fiber type match the optical port. The
transmit port on the local device should be connected to the receive port on the peer device and vice versa.

2.4 Installation Tools

Table 2-2 Installation Tools
Marker, Phillips (crosshead) screwdriver, slotted screwdriver, drill, paper knife, crimping pliers,
diagonal pliers, wire stripper, network cable tester, related power and fiber cables, wrench,
Tools
hammer, cable ties, ESD tools, multimeter
The tool kit and cables are customer supplied.

2.5 Checking before Installation

Please check your materials carefully against the packing list. If there are any errors, please contact your distributor.
·
