Technical Specifications

This section details the specifications and operating conditions of the device.
5.1

Power Supply Specifications

The RUGGEDCOM RSG2100 can be equipped with the following power supplies:
Electrical hazard – risk of power supply failure or damage to the device
Make sure power input to the device is within the specified input range. If power in-
put is too high, damage to the power supply may occur. If power input is too low,
damage to the device may occur.
Hazardous Environments
HI (125/250 VDC)
HI (100/240 VAC)
a
(F) denotes fast-acting fuse
b
(T) denotes time-delay fuse.
c
Power consumption varies based on configuration. 10/100Base-TX ports consume roughly 1 W less than
fiber optic ports.
d
The HI power supply is the same power supply for both AC and DC.
Non-Hazardous Environments
HI (125/250 VDC)
HI (110/230 VAC)
a
(F) denotes fast-acting fuse
b
(T) denotes time-delay fuse.
c
Power consumption varies based on configuration. 10/100Base-TX ports consume roughly 1 W less than
fiber optic ports.
RUGGEDCOM RSG2100
Installation Manual, 03/2020, C79000-G8976-1040-17
CAUTION
Power Sup-
ply Type
Minimum
24 VDC 24 VDC
48 VDC 48 VDC
d
125 VDC
d
100 VAC
Power Sup-
ply Type
Minimum
24 VDC 10 VDC
48 VDC 36 VDC
d
88 VDC
d
85 VAC
Input Range
Maximum
24 VDC
48 VDC
250 VDC
240 VAC
Input Range
Maximum
36 VDC
72 VDC
300 VDC
264 VAC
Internal Fuse Maximum Power
a b
Rating Consumption
2.0 A(F) 28 W
1.0 A(T)
600 mA(T)
600 mA(T)
Internal Fuse Maximum Power
a b
Rating Consumption
6.3 A(F) 28 W
3.15 A(T)
2 A(T)
2 A(T)
