Siemens RUGGEDCOM RSG2100 Installation Manual page 43

Technical Specifications
5.5 Fiber Optic Ethernet Port Specifications
Mode Connec-
tor Type
MM LC
SM ST
SM SC
SM LC
SM SC
SM LC
SM SC
SM LC
a
Typical.
b
Typical distance. The maximum distance is greatly dependent on factors such as cable type, the number of connectors and
number of splices. Consult a Siemens sales associates when determining maximum distances.
Gigabit Ethernet (1 Gbps) Optical Specifications
Note
These transceivers utilize a distributed feedback (DFB) type laser and are rated for -20
to 85 °C (-4 to 185 °F) operation only.
Mode Connec-
tor Type
MM LC
MM LC
SM SC
SM LC
SM SC
SM LC
a
All cabling is duplex type unless specified otherwise.
b
Typical.
c
All optical power numbers are listed as dBm averages.
d
Typical distance. The maximum segment length is greatly dependent on factors such as fiber quality, and the number of
patches and splices. Consult a Siemens sales associates when determining maximum segment distances.
GBIC Gigabit (1 Gbps) Transceiver Specifications
Note
GBIC transceivers have a temperature range of -40 to 85 °C (-40 to 185 °F), unless
specified otherwise.
Mode Connec-
tor Type
SM SC
SM SC
34
Cable Tx λ
a
Type (µm) (nm)
Minimum Maximum
62.5/125 1300
9/125 1310
9/125 1310
9/125 1310
9/125 1310
9/125 1310
9/125 1310
9/125 1310
Cable Tx λ
b
Type (nm)
Minimum Maximum
a
(µm)
50/125 850
62.5/125 850
9/125 1310
9/125 1310
9/125 1310
9/125 1310
Cable Tx λ
b
Type (nm)
Minimum Maximum
a
(µm)
9/125 1310
9/125 1310
Tx (dBm) Rx Sen-
sitivity
(dBm)
-19 -14 -32
-15 -8 -32
-15 -8 -31
-15 -8 -34
-5 0 -34
-5 0 -35
0 5 -37
0 5 -37
c
Tx (dBm) Rx Sen-
sitivity
(dBm)
-9 -2.5 -20
-9 -2.5 -20
-10 -3 -20
-9.5 -3 -21
-5 0 -20
-7 -3 -24
c
Tx (dBm) Rx Sen-
sitivity
(dBm)
-9.5 -3 -21
-7 -3 -24
Rx Sat- Distance
b
uration (km)
(dBm)
-14 2
-3 20
-7 20
-7 20
-3 50
3 50
0 90
0 90
Rx Sat- Distance
d
uration (km)
c c
(dBm)
0 0.5
0 0.5
-3 10
-3 10
-3 25
-3 25
Rx Sat- Distance
d
uration (km)
c c
(dBm)
-3 10
-3 25
RUGGEDCOM RSG2100
Installation Manual, 03/2020, C79000-G8976-1040-17
Pow-
er Bud-
get (dB)
13
17
16
19
29
30
37
37
Pow-
er Bud-
get (dB)
11
11
10
11.5
15
17
Pow-
er Bud-
get (dB)
11.5
17
