Racelogic VBOX User Manual page 21

PIN
1
2
3
4
5
6
Chassis
Connector 2 (Lemo 7 PIN)
PIN
1
2
3
4
5
6
7
I/O
N/A
N/A
I/O
I/O
I
I/O
I
I/O
I
O
O
I
I/O
I
I
https://racelogic.support/Indoor_Positioning/VBOX_Indoor_Positioning_System_(VIPS)/VIPS_User_Guide/
Function
Do not use
Do not use
CAN High
CAN Low
+12 V Power
PPS
Ground
Function
IMU Rx
IMU Tx
VIPS Tx
VIPS Rx
PPS
+12 V Power
Ground
