It is situated close to the fuel pump (1), Fig. A, and provides an
outlet value of variable resistance according to the fuel level.
Check:
•
The resistance depending on fuel level (Fig. B) by position-
ing the multitester on symbol Ω between the PIN1 - PIN2.
Indicated level
Resistive value Ω
Tank fuel (Lt)
Extension (mm)
ACTUATORS
FUEL LEVEL SENSOR
6
5
4
0-18
19-24
25-36
20
15.3
12.7
262
228±3
207±3
1
-
Marrone
Nero
3
2
1
37-52
53-69
70-89
90-95
10
7.7
5.1
186±3
165±3
144±3
112±3
A
B
+
Rosso
Blu
0
2.7
ELE. - 53
