Install:
• washer
• the counter shaft gear nut (6)
Torque 90-100 N*m
Install:
• washer
• drive shaft gear nut (2)
Torque 115-125 N*m
NOTE:________________________________
To keep the two drive shafts still, it is necessary to use the
tool (**) in Fig. S
(**) Gear wrench
Code: 03200097053000
Assemble:
after assembling the two half casings, tighten the screws Fig. Q
to the following torque:
Position screws (40): (M6)
Position screws (41): (M8)
Position screws (42): (M10)
Rotate the complete casing through 180° and tighten the screws
Fig. R to the following torque:
Position screws (38): (M8)
Position screws (36): (M8)
Position screws (34): (M10)
Use Loctite while tightening
Strong Loctite
Casing closure tightness torque
Sequence Size
1 M10:
2 M8:
3 M6:
GEAR BOX
GEAR BOX ASSEMBLY
Phases
1°Phase 12 N.m
2°Phase 24 N.m
3°Phase 45 N.m
1°Phase 12 N.m
2°Phase 30 N.m
1°Phase 10 N.m
2°Phase 12 N.m
S
2
6
(**)
Q
R
