Pin Signal
181 PCIE0_TX-
183 GND
185 LPC_AD0/GPIO0(Q7B300 JP2)
187 LPC_AD2/GPIO2(Q7B300 JP2)
189 LPC_CLK/GPIO4(Q7B300 JP2)
191 SERIRQ/GPIO6(Q7B300 JP2)
193 VCC_RTC
195 FAN_TACHOIN/GP_TIMER_IN
197 GND
199 SPI_MOSI
201 SPI_MISO
203 SPI_SCK
205 VCC_5V_SB
207 MFG_NC0
209 MFG_NC1
211 NC
213 NC
215 NC
217 NC
219 VCC
221 VCC
223 VCC
225 VCC
227 VCC
229 VCC
Board and Pin Assignments
Q7B300 Qseven Module Development Board
Pin Signal
182 PCIE0_RX-
184 GND
186 LPC_AD1/GPIO1(Q7B300 JP2)
188 LPC_AD3/GPIO3(Q7B300 JP2)
190 LPC_FRAME#/GPIO5(Q7B300 JP2)
192 LPC_LDRQ#/GPIO7(Q7B300 JP2)
194 SPKR/GP_PWM_OUT2
196 FAN_PWMOUT/GP_PWM_OUT1
198 GND
200 SPI_CS0#
202 SPI_CS1#
204 MFG_NC4
206 VCC_5V_SB
208 MFG_NC2
210 MFG_NC3
212 NC
214 NC
216 NC
218 NC
220 VCC
222 VCC
224 VCC
226 VCC
228 VCC
230 VCC
