Connectors

Signals go to other parts of the system through connectors. Loose or improper connection
might cause problems, please make sure all connectors are properly and firmly connected.
Here is a summary table which shows all connectors on the hardware.
Connector
CN1
CN2
CN4
CN5
CN6
CN7
CN9
CN10, CN15
CN11
CN12
CN13
CN19, CN21
CN20
CN22
CN23
CN25
CN26
CN31
CN32~CN34
CN37
CN38
CN39
CN40
CN41 (Optional)
12
Description
COM Wafer Connector
Front Panel Connector
SMBus Connector
I2C Connector
CAN Connector
eDP Connector
LVDS Connector
ATX Power Connectors
Fan Connector
Inverter Connector
SATA Power Connectors
SATA Connectors
USB 3.0 Port 2 Wafer Connector
SD Card Slot
Qseven Connector
PCI-Express Mini Card Connector
I2S Connector
Digital I/O Connector
PCI-Express x1 Slots
Ethernet, USB 3.0 Port 0 and 1 Stack
Audio Jack
COM D-Sub Connector
DisplayPort Connector
USB 2.0 Port 1
