Sorbent tube
All-in-One
Tubing
Flow adjust screw
Tubing
Suction port
Pump inlet
Pump
chek-mate calibrator
Figure 4. Calibration Train (5 to 500 ml/min) for Single Tube
Dual adjustable low flow holder
Sorbent tube
Tubing
Flow adjust screw
Tubing
Suction port
CPC
Pump inlet
chek-mate calibrator
Pump
Figure 5. Calibration Train (5 to 500 ml/min) for Multiple Tubes
skcinc.com
Form 37165 Rev 200217
Page 8
