2
PANEL DESCRIPTION
■ Function display

D Software Key area

The Key function for each Software Key is displayed.
See page 5 for details.

D Position and Time area

Position area
The current position is displayed when valid GPS data
is received, or when you manually enter your position.
Indicator
Displayed when a GPS receiver is not
No
connected, and the position data has not
Position
been manually entered.
Blinks every 2 seconds instead of the
position when the GPS position data is
invalid.
L The last position is held for only 23.5 hours.
After that, "No Position" will be displayed.
??
Blinks every 2 seconds instead of the
position after 4 hours have passed since
you manually entered the position data.
L The manually entered data is held for only
23.5 hours. After that, "No Position" will be
displayed.
Date and Time area
• The current time is displayed when valid GPS data
is received, the time is manually entered.
• The date information is displayed when the RMC
GPS sentence formats are included in the GPS
signal.
Indicator
Displayed when a GPS receiver is not
connected and the time has not been
No Time
manually entered.
Displayed when the offset time is set.
Local
Displayed when the time is manually
Manual
entered.
Blinks every 2 seconds instead of the time
when the GPS current time is invalid.
L After 23.5 hours has passed, "No Time" will
be displayed.
Blinks every 2 seconds instead of the
??
time after 4 hours have passed since you
manually entered the time.
L The manually entered time is held for only
23.5 hours. After that, "No Time" will be
displayed.
8
