AMP Research POWERSTEP 76141-01A Installation Manual page 8

Attach step, sliding the mounting T-nut into
position. Align endcap with edge of front door.
1
14
18
On each side of the vehicle measure from the
front edge of door line on the pinch weld to the
specified lengths below. Measure at 20" for front
LED Light and 60" for rear LED Light.
16
20
Using supplied butt connectors, connect the
lamp wires. Red to Red, Black to Black
18
www.amp-research.com www.amp-research.com
A M P R E S E A R C H P O W E R S T E P
9
24"
65"
18
– F O R D F - 1 5 0
T M
9
2
2
15
19
Affix lamps to rocker panel surface. Make sure
the lamp is affixed to a clean, flat surface. There
is a step down midway across the surface. Affix
lamp just outside of step down.
17
Close and wrap with conduit and electrical tape.
Secure all loose wires with cable ties, with lamp
wires pulled upward to avoid any wire snagging.
19
8/9 8/9
1
Torque
10 ft-lbs.
(13.5 Nm)
12
IM76141 rev 01.20.20
