SM Series

Specifications and Features

Operating frequencies:
Block 21 537.600 - 563.100
Block 22 563.200 - 588.700
Block 23 588.800 - 607.900 and 614.100 - 614.300
Block 24 614.400 - 639.900
Block 25 640.000 - 665.500
Block 26 665.600 - 691.100
Block 27 691.200 - 716.700
Block 28 716.800 - 742.300
Block 29 742.400 - 767.900
Block 944 944.100 - 951.900
(Not all frequencies are usable in some countries)
Frequency range:
Channel Spacing:
Frequency selection:
RF Power output:
Compatibility Modes (6)
Pilot tone:
Frequency stability:
Deviation:
Spurious radiation:
Equivalent input noise:
Input level:
If set for dynamic mic:
If set for electret lavaliere mic:
Line level input:
Input impedance:
Dynamic mic:
Electret lavaliere:
Line level:
The FCC requires that the following statements be
included in this manual:
This device complies with FCC radiation exposure limits as
set forth for an uncontrolled environment. This device should
be installed and operated so that its antenna(s) are not co-
located or operating in conjunction with any other antenna or
transmitter.
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions: (1) This
device may not cause harmful interference, and (2) this device
must accept any interference received, including interference
that may cause undesired operation.
0
256 frequencies in 100 kHz steps
for one 25.5 MHz wide block
100 kHz
Control panel mounted membrane switches
SM: 100 mW (nominal)
SMD: 100 mW (nominal)
SMQ: 250 mW (nominal)
Digital Hybrid Wireless™ (400 Series),
200 Series, 100 Series, Mode 3
(other analog), Mode 6, and IFB
25 to 32 kHz; 5 kHz deviation
(in 400 Series Mode)
± 0.002%
± 75 kHz max. (in 400 Series Mode)
60 dB below carrier
–125 dBV, A-weighted
0.5 mV to 50 mV before limiting.
Greater than 1 V with limiting.
1.7 uA to 170 uA before limiting.
Greater than 5000 uA (5 mA) with limiting.
5.0 mV to 6 V before limiting.
Greater than 15 V with limiting.
300 Ohms
Input is virtual ground with servo adjusted
constant current bias
2.7 k Ohms
Input limiter:
Bias voltages:
Gain control range:
Modulation indicators:
Low frequency roll-off:
Controls: C ontrol panel with LCD and four
Audio Frequency Response:
Signal to Noise Ratio (dB):
(overall system, 400 Series mode)
(Note: the dual envelope "soft"
limiter provides exceptionally
good handling of transients
using variable attack and release
time constants. The gradual onset of limiting in the design begins below full
modulation, which reduces the measured figure for SNR without limiting by 4.5 dB)
Total Harmonic Distortion:
Audio Input Jack:
Antenna: Flexible, unbreakable steel cable.
Batteries:
Battery Life:
Weight:
SMD/Q: 3.7 oz.. (105 grams) with lithium batteries
Overall Dimensions:
SM/RM: 2.3 x 1.8 x 0.64 inches
SMD/Q: 2.3 x 2.4 x 0.64 inches
Emission Designator: 180KF3E
Specifications subject to change without notice.
For body worn operation, this SM Belt-Pack Transmitter has
been tested and meets the FCC RF exposure guidelines
when used with the Lectrosonics accessories supplied or
designated for this product. Use of other accessories may
not ensure compliance with FCC RF exposure guidelines.
Contact Lectrosonics if you have any questions or need more
information about RF exposure using this product.
Soft limiter, 30 dB range
Fixed 5 V at up to 5 mA
Selectable 2 V or 4 V servo bias for any
electret lavaliere.
40 dB; panel mounted membrane switches
Dual bicolor LEDs indicate modulation of
–20, -10, 0, +10 dB referenced to
full modulation.
–18 dB/octave; 70 Hz
membrane switches.
35 Hz to 20 kHz, +/-1 dB (The audio is
deliberately rolled off at 70 Hz using a
18 dB/octave filter. This filter cannot be
disabled.)
SmartNR No Limiting
OFF 103.5
NORMAL 107.0
FULL 108.5
0.2% typical (400 Series mode)
Switchcraft 5-pin locking (TA5F)
1.5 Volt AA lithium or rechargeable
NiMH recommended
SM: 1.5 hours (alkaline); 5.5 hours (lithium),
4 hours with 2500mAh NiMH
SMD: 5.75 hours (alkaline); 14.25 hours (lithium),
8.5 hours with 2500mAh NiMH
SMQ: 1.75 hours (alkaline); 7.5 hours (lithium),
5 hours with 2500mAh NiMH
RM: 2.3 oz.. (65.8 grams) with lithium battery
SM: 2.7 oz.. (75.9 grams) with lithium battery
(not including microphone/lanyard)
58 x 46 x 16 mm
(not including microphone/lanyard)
(not including microphone)
58 x 60 x 16 mm
(not including microphone)
LECTROSONICS, INC.
w/Limiting
108.0
111.5
113.0
