Operating Notes

• The SM's sensitivity to the
remote control varies with
the transmitter's audio level
setting and the microphone
used, but it is always possible
to make it work with a suf-
ficiently loud remote signal at
close range.
• If the SM is configured to re-
spond to the remote control,
it will do so even if the but-
tons are locked.
• When the SM is asleep, it can
only be awakened by the re-
mote control, or by removing
and reinserting the battery.
• When the SM is asleep, the
PWR led blinks green every
few seconds.
• If a remote command is sent that would result in
the same display being shown again on the SM (for
example tuning to the channel already displayed),
a row of dashes is displayed briefly, as a signal that
the command was received, but it didn't change
anything.
• If you are having trouble getting the SM to respond,
make sure you aren't covering the RM's speaker
with your thumb, and/or turn up the RM's speaker
volume on the "Loud" page.
• If the RM is set to a different block number than
the transmitter and an attempt is made to set the
transmitter's frequency in MHz, the command
will still work. The transmitter is simply set to the
corresponding channel in the correct block, with a
matching hex code.
• Since all SM transmitters respond to the same sig-
nals, take care that the remote control is presented
only to the desired transmitter, with the minimum
speaker volume necessary to do the job reliably.
Rio Rancho, NM
Super-Minature Belt Pack Transmitters
The RM should be held close enough to the microphone to
change the settings on the desired SM, but not be so loud as
to affect other SM units nearby.

RM Quick Reference

Power On/Off
Set SM audio level
Sleep or Wake SM
Lock or Unlock SM
Adjust RM volume
Set SM channel (hex)
Enable MHz display
Set SM channel (MHz)
AUDIO+FREQ
Aud page (via AUDIO)
SLEEP/unSLP page (via AUDIO)
Loc/unLoc page (via AUDIO)
Loud page (via AUDIO)
CH page (via FREQ)
b (block) page (via FREQ)
000.000 page (via FREQ)
