UH400A/UH400TM

Specifications and Features

Operating frequencies:
Frequency selection:
RF Power output:
Pilot tone:
Frequency stability:
Deviation:
Spurious radiation:
Equivalent input noise:
Input level:
Input impedance:
Phantom power:
Input limiter:
Gain control range:
Modulation indicators:
Low frequency roll-off:
Controls:
Audio Frequency Response:
Signal to Noise Ratio (dB):
Note: The dual envelope "soft" limiter provides
exceptionally good handling of transients using
variable attack and release time constants.
Once activated, the limiter compresses 30+ dB
of transmitter input range into 4.5 dB of receiver
output range, thus reducing the measured figure f
or SNR without limiting by 4.5 dB
Total Harmonic Distortion:
Antenna:
Battery Type:
Battery Life:
Weight:
Overall Dimensions:
Emission Designator:
Specifications subject to change without notice.
The FCC requires that the following statement be included in this manual:
This device complies with FCC radiation exposure limits as set forth for an uncontrolled environment. This device
should be installed and operated so that its antenna(s) are not co-located or operating in conjunction with any other
antenna or transmitter.
14
470.100 to 607.900 MHz; 614.100 to 767.900 MHz
256 frequencies in 100 kHz steps
100 mW
25 to 32 kHz; 5 kHz deviation (in 400 Series (hybrid) mode)
± 0.002%
± 75 kHz max. (in 400 Series mode)
60 dB below carrier
–118 dBV, A-weighted
Nominal 2 mV to 300 mV, before limiting; Greater than 1.0 V maximum, with limiting.
1 k Ohm
Selectable; 5, 15, 48 VD (see details in Controls and Functions section)
Soft limiter, >30 dB range
43 dB; semi-log rotary control
Dual bi-color LEDs indicate modulation of –20, -10, 0 and +10 dB referenced to full modulation.
–12 dB/octave; 70 Hz (35 Hz for UH400TM)
Control panel knob adjusts audio gain.
Rotary switches on bottom panel adjust transmitter frequency.
90 Hz to 20 kHz, +/-1 dB (40 Hz to 20 kHz, +/- 1 db for UH400TM)
Note: The audio is deliberately rolled off at 70Hz using a 12 dB/octave filter on the UH400A. This filter cannot be disabled.
SmartNR No Limiting w/Limiting
OFF 103.5 108.5
NORMAL 107.0 111.5
FULL 108.5 113.0
0.2% typical (400 Series mode)
Built-in; housing and input coupler form a dipole configuration
9V Li Polymer rechargeable, Lithium
4.5 Hours with alkaline or Li Polymer, 12 hrs with lithium
(Battery life will vary with battery brand, phantom power voltage setting and mic current drain.)
7.873 oz. 223.2 grams with lithium battery, no mic
1.5 x 1.5 x 4.2 inches (Not including microphone.)
190KF3E
