Table 10. STEVAL-ISF00V1 BOM (continued)
Ref. Part/value Toll.%
L1 B82725A2802N1
L2 900 µH-10 Apk
L3 1 mH +/-10% 290 mA
Q1 STW23NM60N
Heat-
sink for Heatsink for Q1
Q1 and and D4
D4
Q2,Q3 BC847
RL1 Small relay
R1 330 kΩ +/-1%
R2,R6,
220 kΩ +/-1%
R7
R3 82 kΩ +/-1%
R4,
4.7 kΩ +/-1%
R10
R5,
470 kΩ +/-5%
R35
R8 100 kΩ +/-1%
47 Ω
R9 +/-5%
www.BDTIC.com/ST
Voltage/ Technology
Watt
current information
Power line
choke
Radial inductor Through Hole
N-channel
600 V - 0.150 Ω
- 19 A, second
generation
MDmesh™
power
MOSFET
Heatsink for
STW23NM60N
and
STTH12S06
(100,00 mm)
NPN transistor
12 V/ Mini power
10 A PCB relay
0.6 W Resistor
0.6 W Resistor
0.6 W Resistor
0.6 W Resistor
1/4 W Resistor
1/4 W Resistor
1/4 W Resistor
Package Manufacturer
Vertical B82725A2
Epcos
through hole
Wurth Elektronik 744741102 RS code: 488-9964
STW23NM
TO-247 ST Microelectronics
Aavid Thermalloy
SOT23 NXP
T7SS5E6-
Through hole Tyco Electronics
Through hole
Through hole
Through hole
Through hole
Through hole
Through hole
SMD 1206
Manuf. RS/distrelec/other
More
info
code code
Distrelec code:
802N1 351190
60N
78075
BC847 RS code: 436-7953
RS code: 616-8714
12
RS code: 149-105
RS code: 149-060
RS code: 148-950
RS code: 148-663
RS code: 148-972
