Starting the PFC application

7 Starting the PFC application
This chapter explains how to configure the demonstrator.
7.1

Hardware requirements

●
STEVAL-ISF002V1 PFC power board
●
34-pin flat cable
●
AC power source able to supply the appropriate voltage and current
●
DC electronic load able to provide the appropriate load
●
STEVAL-IHM022V1 dual motor control demonstration board
●
5 V / 2 A DC power supply to supply the STEVAL-IHM022V1
●
J-Link-ARM-KS
●
USB cable (A and B type plug)
●
20-pin flat cable
●
PC
7.2

Software requirements

●
IAR embedded workbench for ARM 5.20
●
IAR project for digital PFC based on the STM32F103ZE microcontroller
The software demonstration source code is provided by STMicroelectronics free of charge
(after acceptance of the license agreement during the installation procedure).
The firmware can be customized with your own preferred development tool and downloaded
into the internal Flash memory of the STM32 through a JTAG interface present on the
STEVAL-IHM022V1.
7.3

Jumper settings

Table 3 and
STEVAL-IHM022V1 demonstration board respectively. Note that
jumpers used from the digital PFC; all other jumper settings must be left as default.
Table 3.
Name
JP9
40/62
www.BDTIC.com/ST
Table 4 show the jumper settings for the STEVAL-ISF002V1 power board and
PFC power board STEVAL-ISF002V1 jumper settings
Selection
VIPER12 is enabled. J10 connector must be open.
1 2
VIPER12 is disabled. 15 V must be provided by J10 connector.
1 2
