BYOC Optical Compressor Instructions Manual page 7

Hide thumbs Also See for Optical Compressor:

Advertisement

STEP 2: Add the diode. The 1N4001 will be black with a silver stripe. Be sure to
matched the end of the diode with the stripe to the layout on the PCB. The stripped end
should go in the square solder pad.
