BART LABDMM2 User Manual page 38

LABDMM2
TLDMM
(2)
ACCREDIA Certificate in RELATIVE mode.
ACCREDIA calibration in ABSOLUTE mode CAN NOT be performed by the LAT Center N ° 093.
On request it can be commissioned to other accredited calibration Centers.
(3) ACCREDIA calibration CAN NOT be performed by the LAT Center N ° 093.
On request it can be commissioned to other accredited calibration Centers.
The installation and maintenance of the product must be made only by trained personnel and after reading this
manual.
It will also be observed all safety standards under current legislation in the country where it will be installed.
The pressure gauge must not be used for purposes other than those indicated in the "Field of Application":
otherwise BART transducers disclaims any liability.
In particular it is noted that the product supplied is not a safety device.
BART in the design has taken every precaution to minimize the risk to your safety, but recommends
that responsible for installing the analysis and removal of any residual risks.
Remember that the safe use of the product requires its complete integrity: why should be paid attention to the
transportation and storage.
In the following pages are identified tricky operations and / or possible sources of risk to the user
or equipment with the symbol by side.
USER GUIDE
12. PURCHASING CODES
Pressure
R = Relative
A = Absolute (2)
Example: T L D M M 2 R C X 4 1 5 0 B S
TDMMV Relative Vacuum version
13. SAFETY WARNINGS
CX41 Full Scale
0B1 5B
0B2 10B
0B5 20B
1B 50B
2B5 100B
Pag. 10
MO.LABDMM2.560.ENG.R1
OPTION
250B 1KB5 S = RS232C
350B 2KB W = WIRELESS
(3)
500B 2KB5
700B 3KB (3)
1KB
