  • Page 1 Veritas NetBackup™ 5230 Appliance and Storage Shelf Product Description...
  • Page 2 Technologies LLC or its affiliates in the U.S. and other countries. Other names may be trademarks of their respective owners. This product may contain third party software for which Veritas is required to provide attribution to the third party (“Third Party Programs”). Some of the Third Party Programs are available under open source or free software licenses.
  • Page 3 Include the document title, document version, chapter title, and section title of the text on which you are reporting. Send feedback to: APPL.docs@veritas.com You can also see documentation information or ask a question on the Veritas community site: http://www.veritas.com/community/ Veritas Services and Operations Readiness Tools (SORT) Veritas Services and Operations Readiness Tools (SORT) is a website that provides information and tools to automate and simplify certain time-consuming administrative tasks.

  • Page 4: Table Of Contents

    About the 2-port 8 Gb FC HBA ............18 About the dual-port 10 Gb Ethernet card ........... 19 About the Veritas 3U16 24TB Storage Shelf / Veritas 3U16 36TB Storage Shelf ................ 19 Appliance and storage shelf connections ........... 21 NetBackup 5230 documentation ............
  • Page 5 Contents Veritas 2U12 49TB Storage Shelf rear components ....... 39 Index ........................48...

  • Page 6: Product Overview

    ■ About the 2-port 8 Gb FC HBA ■ About the dual-port 10 Gb Ethernet card ■ About the Veritas 3U16 24TB Storage Shelf / Veritas 3U16 36TB Storage Shelf ■ Appliance and storage shelf connections ■ NetBackup 5230 documentation ■...
  • Page 7 Note: You can purchase additional 64-GB memory kits to maximize the amount of memory in the NetBackup 5230 Appliance. You can also use the memory kits to increase the appliance memory when you add an optional storage shelf to the system.
  • Page 8 An appliance with 14-TBs of internal storage and one or more ■ storage shelves contains sixteen 8Gb DIMMs. Fibre Channel support The NetBackup 5230 appliance can be ordered with up to five FC HBA cards preinstalled. A 10Gb Ethernet card can also be ordered and preinstalled.

  • Page 9: About Storage Capacity

    Note: The disk drives in slots 0 and 1 of the appliance are 1-TB drives. These drives provide the operating system for the appliance. To expand the NetBackup 5230 Appliance storage capacity, you can connect up to four storage shelves to the appliance.
  • Page 10 NetBackup 5230 Appliance. Note: Storage shelves use disk drives with capacities of 2-TB, 3-TB, or 6-TB, depending on the storage shelf model. “About the Veritas 3U16 24TB Storage Shelf / Veritas 3U16 36TB Storage Shelf” on page 19.

  • Page 11: About Best Practices For Rack Installation

    36TB Storage Shelves. However, you must connect the 2U12 49TB Storage Shelf to the last 3U16 24TB or 36TB Storage Shelf that is connected to the appliance. For example, NetBackup 5230 Appliance + 3U16 24TB Storage Shelf + 3U16 24TB Storage Shelf + 3U16 36TB Storage Shelf + 2U12 49TB Storage Shelf.

  • Page 12: About The Appliance Rear Panel

    If the distance between rack posts is longer than 36” (914mm) the rails and the appliance cannot be properly installed. The width of the storage shelf is 19” (482.6mm). If your rack dimensions do not conform to these requirements contact Veritas ■ Technical Support.
  • Page 13 Product overview About the appliance rear panel Rear panel connectors and features Table 1-3 Number Function 1, 2 Power Supply Modules #1, #2 (120VAC) NIC1/eth0, a 1Gb connector that is reserved for private management usage By default, NIC1 (eth0) is factory set to IP address 192.168.229.233. This private network address is reserved to provide a direct connection from a laptop to perform the initial configuration of the appliance.
  • Page 14 Product overview About the appliance rear panel The ports on the rear panel are color-coded for easy identification. Rear panel port colors Figure 1-3 The rear panel has two sets of low profile, full height, 3.5" form factor PCIe slots. The following diagram shows the slot numbers 1 through 6.

  • Page 15: About The Mainboard Raid Controller

    Product overview About the mainboard RAID controller The NetBackup 5230 appliance add-in cards are available in five configurations. Several configurations include at least one FC HBA card for VMware, Optimized Deduplication over FC, or tape library connectivity. In some configurations the FC HBA cards are installed into some of the PCIe slots.

  • Page 16: About The Netbackup 5230 Rear Panel Configurations

    NetBackup 5330 Appliance's attached Primary Storage Shelf. About the NetBackup 5230 rear panel configurations The NetBackup 5230 appliance ships in the following configurations. The external storage shelves can be ordered as separate devices. NetBackup 5230 rear panel configurations...
  • Page 17 Product overview About the NetBackup 5230 rear panel configurations NetBackup 5230 rear panel configurations (continued) Table 1-4 Configuration Slot 1 Slot 2 Slot 3 Slot 4 Slot 5 Slot 6 Dual 8 Gb RAID populated populated Fibre populated populated (with an controller Channel external...

  • Page 18: About The Fc Hba Port Configurations

    “About the FC HBA port configurations” on page 18. About the FC HBA port configurations The NetBackup 5230 appliance add-in cards are available in five configurations. Several configurations include one FC HBA card for VMware, Optimized Deduplication over FC, or tape library connectivity.

  • Page 19: About The Dual-Port 10 Gb Ethernet Card

    NetBackup™ 5240 Appliance and NetBackup 5240 Storage Shelf Product Description or the Veritas NetBackup™ 5330 Appliance Product Description for more information. “About the Veritas 3U16 24TB Storage Shelf / Veritas 3U16 36TB Storage Shelf” on page 19. About the Veritas 3U16 24TB Storage Shelf /...
  • Page 20 Product overview About the Veritas 3U16 24TB Storage Shelf / Veritas 3U16 36TB Storage Shelf Veritas 3U16 24TB Storage Shelf / Veritas 3U16 36TB Storage Figure 1-7 Shelf front panel Table 1-6 lists the 3U16 storage shelf front panel components that are shown in Figure 1-7.

  • Page 21: Appliance And Storage Shelf Connections

    Product overview Appliance and storage shelf connections Veritas 3U16 24TB Storage Shelf / Veritas 3U16 36TB Storage Table 1-7 Shelf rear panel components Number Component Serial port Release latch I/O module #1 SAS_IN port SAS_OUT port I/O module #2 Power supply #1 and fans...
  • Page 22 Product overview Appliance and storage shelf connections Connecting the NetBackup 5230 appliance and two storage Figure 1-10 shelves Table 1-8 describes the configuration of an appliance and two storage shelves. Appliance connection to two storage shelves Table 1-8 Number Component...
  • Page 23 Product overview Appliance and storage shelf connections Starting with the NetBackup Appliance release 2.6.0.3, the use of up to four storage shelves with one appliance is supported. Table 1-8 also lists the components in the four-shelf configuration. Four storage shelves and one appliance Figure 1-11...

  • Page 24: Netbackup 5230 Documentation

    Product overview NetBackup 5230 documentation “About the Veritas 3U16 24TB Storage Shelf / Veritas 3U16 36TB Storage Shelf” on page 19. NetBackup 5230 documentation The NetBackup 5230 appliance runs NetBackup appliance software to provide deduplication and advanced storage backup capabilities. Documentation for the appliance and for the NetBackup software is available at the following link.

  • Page 25: Cables

    Chapter Cables This chapter includes the following topics: Power cables ■ Network cable ■ Multi-Mode fiber optic cable ■ SAS cable ■ Power cables The AC power modules of the appliance and the storage shelves accept one AC power cable. One end of the AC power cable is connected to the power supply on the appliance or the storage device.

  • Page 26: Network Cable

    AC power connector (IEC-60320-C13) to an appliance or a storage device. Note: If your power distribution unit is not compatible with the IEC-60320-C13 plug, then Veritas recommends that you purchase your power cable locally. Make sure the power cable meets or exceeds the indicated power rating.

  • Page 27: Sas Cable

    Cables SAS cable Multi-Mode fiber optic cable Figure 2-3 Fiber optic cables require Small Form-factor Pluggable (SFP+) transceivers, which are provided with each device having Fibre Channel ports. The diagram shows the SFP, labeled 1, and the fiber optic cable which is attached to it, labeled 2. Supported SFPs are listed: Finisar ■...
  • Page 28 Cables SAS cable SAS cable Figure 2-4 Refer to the NetBackup Appliance and storage shelf connection sections as needed for details.

  • Page 29: Technical Specifications, Standards, And Compliance Information

    Chapter Technical specifications, standards, and compliance information This chapter includes the following topics: Technical specifications ■ Environmental specifications ■ Protocol standards ■ Technical specifications Appliance technical specifications Table 3-1 provides technical specifications for the 5230 Appliance. Table 3-2 provides technical specifications for the 5230 Appliance storage shelf. Appliance technical specifications Table 3-1 Parameter...
  • Page 30 Note: You can purchase additional 64-GB memory kits to maximize the amount of memory in the NetBackup 5230 Appliance. You can also use the memory kits to increase the appliance memory when you add an optional storage shelf to the system.
  • Page 31 Technical specifications, standards, and compliance information Technical specifications Appliance technical specifications (continued) Table 3-1 Parameter Description Acoustic noise Sound power: 7.0 dB in operating condition at typical office ambient temperature. (23°C +/- 2) System Cooling Requirement 460W typical – 1570 BTU/hour 750W maximum –...

  • Page 32: Environmental Specifications

    Technical specifications, standards, and compliance information Environmental specifications Storage shelf technical specifications (continued) Table 3-2 Parameter Description Power supplies Dual 580W, 100 - 240 VAC auto ranging, 50-60 Hz, hot swappable power supplies Power consumption 326 W at 110 V 372 W at 220 V Power parameters AC voltage range:...

  • Page 33: Protocol Standards

    Technical specifications, standards, and compliance information Protocol standards Environmental requirements (continued) Table 3-3 Component Requirement Storage altitude -30 meters to 3,000 meters Noise < 72 A-weighted decibel This value reflects the maximum noise of the appliance when the ambient temperature is 25°C. “Protocol standards”...

  • Page 34: About The Optional Veritas 2U12 49Tb Storage Shelf

    ■ Veritas 2U12 49TB Storage Shelf overview The optional Veritas 2U12 49TB Storage Shelf is a 2U12 drive enclosure that contains twelve 6TB 7200 rpm SAS hard disk drives. Available storage capacity of the storage shelf is 49TBs. Each disk drive can be accessed from the storage shelf's front panel.

  • Page 35: Components Of The Veritas 2U12 49Tb Storage Shelf

    They are not used during normal appliance operations. Along with the I/O modules and the disk drives, the Veritas 2U12 49TB Storage Shelf also includes a front control panel. The control panel provides LED indications of the health of the storage shelf.
  • Page 36 Indicator Aperture Drive tray Status LEDs The following table describes the disk drive carrier LEDs. Note that the combination of both LEDs provides the status. Veritas 2U12 49TB Storage Shelf disk drive carrier LED status Table A-1 Status Activity (green) LED Fault (amber) LED No disk drive installed.
  • Page 37 T10 screw driver. Veritas 2U12 49TB Storage Shelf control panel The Veritas 2U12 49TB Storage Shelf control panel is installed on the front left side of the storage shelf. Veritas 2U12 49TB Storage Shelf control panel...
  • Page 38 About the optional Veritas 2U12 49TB Storage Shelf Components of the Veritas 2U12 49TB Storage Shelf Veritas 2U12 49TB Storage Shelf control panel functions Table A-2 Number Item Description Input switch The Input switch enables you to set the Unit Identification display.
  • Page 39 N/A - Not Applicable For more information, see the NetBackup Appliance Hardware Installation Guide - Release 3.0 - NetBackup 5240. Veritas 2U12 49TB Storage Shelf rear components This section describes the rear panel features of the Veritas 2U12 49TB Storage Shelf.
  • Page 40 “Veritas 2U12 49TB Storage Shelf I/O modules” on page 40. “Veritas 2U12 49TB Storage Shelf Power Cooling Modules” on page 44. “Power Cooling Module LEDs” on page 45. Veritas 2U12 49TB Storage Shelf I/O modules This section discusses the Veritas 2U12 49TB Storage Shelf I/O modules.
  • Page 41 Components of the Veritas 2U12 49TB Storage Shelf Veritas 2U12 49TB Storage Shelf I/O module Figure A-5 The following figure and table provides details of the two Veritas 2U12 49TB Storage Shelf I/O module canisters. Veritas 2U12 49TB Storage Shelf I/O modules...
  • Page 42 About the optional Veritas 2U12 49TB Storage Shelf Components of the Veritas 2U12 49TB Storage Shelf Veritas 2U12 49TB Storage Shelf I/O module components Table A-5 Number Description I/O module 0 I/O module 1 I/O module Status LEDs “I/O module Status LED location and conditions”...
  • Page 43 About the optional Veritas 2U12 49TB Storage Shelf Components of the Veritas 2U12 49TB Storage Shelf I/O module Status LED conditions (continued) Table A-6 Condition Activity Fault LED (amber) LED (green) The I/O module is off. ID (blue) The I/O module controller is being identified.
  • Page 44 42. Veritas 2U12 49TB Storage Shelf Power Cooling Modules The Veritas 2U12 49TB Storage Shelf includes two Power Cooling Modules (PCM). The dual PCMs provide redundant power to the storage shelf. If one PCM fails, the storage shelf continues to operate as the second PCM continues to supply the storage shelf with power.
  • Page 45 About the optional Veritas 2U12 49TB Storage Shelf Components of the Veritas 2U12 49TB Storage Shelf Power Cooling Module components Table A-8 Number Component Power Cooling Module LEDs “Power Cooling Module LEDs” on page 45. On/Off switch Release tab AC power socket...
  • Page 46 About the optional Veritas 2U12 49TB Storage Shelf Components of the Veritas 2U12 49TB Storage Shelf Power Cooling Module LEDs Figure A-10 Power Cooling Module LED legend Table A-9 Number LED condition AC fail Fan fail Power Cooling Module OK...
  • Page 47 About the optional Veritas 2U12 49TB Storage Shelf Components of the Veritas 2U12 49TB Storage Shelf Power Cooling Module LED conditions (continued) Table A-10 Status Power Fan Fail AC Fail DC Fail Cooling (Amber) (Amber) (Amber) Module OK (Green) Power Cooling Module fan...
  • Page 48 3U16 storage shelf 19 features 19 documentation 24 front panel 19 drive bay slot assignments rear panel 20 Veritas 2U12 49TB Storage Shelf 35 8 Gb Fibre Channel HBA 18 Fibre Channel card 18 appliance FTMS connecting to a storage shelf 21...
  • Page 49 Index Veritas 2U12 49TB Storage Shelf (continued) overview 34 PCIe add-in cards Power Cooling Modules (PCM) 44 10 Gb Ethernet card 19 rear components 39 8 Gb Fibre Channel HBA 18 appliance configurations 16 riser assemblies 14 slot numbers 14...
