Parts List:
Please identify and verify that you have all of
the hardware shown. Please refer to photos in the
instructions for the parts listed below:
Part
Description
3000B
Brackets, 4 pc. set (2 pairs) . . . . . . . . . . . . . 1
3000P
NoDrill Plate . . . . . . . . . . . . . . . . . . . . . . . . . 1
4973
NoDrill Plate Hdw. . . . . . . . . . . . . . . . . . . . . 1
4406
6" Ultra Track . . . . . . . . . . . . . . . . . . . . . . . . 2
Model 3000 also includes the parts below:
4436
36" Ultra Track . . . . . . . . . . . . . . . . . . . . . . . 2
4016
16" Double Track . . . . . . . . . . . . . . . . . . . . . 2
Model 3002 also includes the parts below:
4448
48" Ultra Track . . . . . . . . . . . . . . . . . . . . . . . 2
4024
24" Double Track . . . . . . . . . . . . . . . . . . . . . 2
Model 3004 also includes the parts below:
4460
60" Ultra Track . . . . . . . . . . . . . . . . . . . . . . . 2
4032
32" Double Track . . . . . . . . . . . . . . . . . . . . . 2
Part#
Description
Qty.
PAD1
Glide Pad
8
Part#
Description
Qty.
5760B
Oval Nut
12
Part#
Description
Qty.
HB020
3/4" Bolt
10
Part#
Description
Qty.
HB030
1" Bolt
10
Quantity
Part#
Description
Qty.
MF006
5/8" screw
4
Part#
Description
Qty.
STP004
1/2" Screw
16
Part#
Description
Qty.
WB002
Washer
18
Part#
Description
Qty.
BUSH050 3/8" Spacer
10
3000, 3002 & 3004
Planing Sled
Owners Manual
Please Read Carefully!
Part#
Description
Qty.
CAB015
Angle Bracket
8
Part#
Description
Qty.
NUT006
Acorn Nut
4
Part#
Description
Qty.
5521
1/4" Knob
Part#
Description
5860
Ratchet Handle
Part#
Description
5590
Knob
2
Qty.
4
Qty.
2
Advertisement
Related Manuals for Woodhaven 3000
Summary of Contents for Woodhaven 3000
- Page 1 4406 6" Ultra Track ......2 Model 3000 also includes the parts below: 4436 36" Ultra Track ..... . . 2 4016 16"...
- Page 2 BEFORE BEGINNING The Planing Sled must be setup and used on a flat surface. Identify and verify that you have all the parts listed. You'll need a 7/16" wrench for assembly. Read the instructions carefully at least once before beginning. ASSEMBLY - ROUTER SLED Follow the directions in the 4973 Plate Hardware and attach your router to the Router Plate (3000P).
- Page 3 The rails must be straight and longer than the part length by at least 12" (for the 3000 Planing Sled) or 16-20" (for the 3002 & 3004 Planing Sleds). See fig. 9 & 10 (on next page).
- Page 4 1-1/2" x 2-1/4", 3/4" x 3-1/2" and 1/2" x 3-1/2" material. The rails must be straight and longer than the part length by at least 12" (for the 3000 Planing Sled) or 16-20" (for the 3002 & 3004 Planing Sleds). See fig. 11.
