Woodhaven 8625 Quick Start Manual

Parts List:
Part Description
8625B Plate Marking Base . . . . . . . . . . . . . . . . 1
8610A 1/2" Cap . . . . . . . . . . . . . . . . . . . . . . . . . . 1
8610C 1/4" Cap . . . . . . . . . . . . . . . . . . . . . . . . . . 1
8610D Indexing Plate . . . . . . . . . . . . . . . . . . . . . 1
8610E Indexing Plate Riser . . . . . . . . . . . . . . . 1
4208 7-7/8" One Track . . . . . . . . . . . . . . . . . . 1
PLUS the hardware shown below:
Part# Description
5771B 3/4" Screw
Part# Description
MP150 1-1/2" Screw
Part# Description
BUSH001 1/8" Spacer
Part# Description
BUSH050 3/8" Spacer
1
Quantity
Qty. Part# Description
2 MF035 1/2" Screw
Qty. Part# Description
2 5521 Thumb Nut
Qty. Part# Description
3 MP200 2" Screw
Qty. Part# Description
5 BUSH004 5/8" Spacer
8625 Adjustable
Plate Marking Jig
Please Read Carefully!
Qty. Part# Description
2 HB030 1" Bolt
Qty. Part# Description
1 HB050 1-1/2" Bolt
Qty.
1
Part# Description
5860 Ratchet Handle 1
Qty.
2
Part# Description
5765B Offset Oval Nut 2
Qty. Part# Description
1 WB002 Washer
Qty. Part# Description
1 BUSH5050 1/2" Spacer
Part# Description
Qty.
5863 Ratchet Handle 1
Qty.
Qty.
1
Qty.
1
