Parts List:
Please identify and verify that you have all of the
hardware shown below prior to assembly.
Parts listed below are not shown in the hardware
drawings. Refer to photos in the instructions:
Part
Description
3210A
15-7/8" One Track . . . . . . . . . . . . . . . . . 1
3210B
5-5/8" sq. Axis Base, MDF . . . . . . . . . . 1
3210C
7-5/8" sq. Axis Base, MDF . . . . . . . . . . 1
3210P
Pivot . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
4206
6" One Track . . . . . . . . . . . . . . . . . . . . . . 1
4212
12" One Track . . . . . . . . . . . . . . . . . . . . . 1
3205B
Scribe Pencil Holder . . . . . . . . . . . . . . . 1
Part#
Description
Qty.
5505
3/4" Thumb Screw 2
Part#
Description
Qty.
BUSH001 1/8" Spacer
2
Quantity
Part#
Description
Qty.
5750B
10-24 Oval Nut 2
Part#
Description
Qty.
MP043
7/16" Screw
2
3210
Small Oval Jig
Owners Manual
Please Read Carefully!
Part#
Description
SFP008
1" Screw
Part#
Description
5760B
1/4-20 Oval Nut 2
Qty.
Part#
Description
4
5765B
Offset Oval Nut 1
Qty.
Part#
Description
MF005
1/2" Screw
Qty.
Qty.
1
Advertisement
Related Manuals for Woodhaven 3210
Summary of Contents for Woodhaven 3210
-
Page 1: Parts List
3210 Small Oval Jig Owners Manual Please Read Carefully! Parts List: Please identify and verify that you have all of the hardware shown below prior to assembly. Parts listed below are not shown in the hardware drawings. Refer to photos in the instructions:... - Page 2 BEFORE BEGINNING 1/4” Spacing Identify and verify that you have all the parts listed. Read the instructions at least once, familiarizing yourself with the parts before beginning. You'll need a #2 Phillips screwdriver for assembly. The Small Oval Jig is designed to be used with a stationary belt or disk sander to sand the outside of ovals.
- Page 3 Both pivots should be tightened in the One Track, but still be able to pivot on the screw. The size of the oval is controlled by the distance from the tool to the pivots. Coarse adjustments in oval sizes should be set by moving both pivots to the approximate dimensions needed.
- Page 4 13” x 17-25” 41-49” x 53” 4” to 12” differential or 3210 smaller), but this will reduce the differential range. Note that the 3250 measurements do not cover the full 3230 Oval Jig potential differential range available in this jig because it 25”...
