Woodhaven EZ Lift 1429 Owner's Manual

Advertisement

1429 & 1430
EZ Lift
Owners Manual
U.S. Patent #6,742,558
Please read carefully!
Tools needed for assembly:
Phillips screwdriver
Tools needed for use:
9/16" socket & wrench

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EZ Lift 1429 and is the answer not in the manual?

Questions and answers

Summary of Contents for Woodhaven EZ Lift 1429

  • Page 1 1429 & 1430 EZ Lift Owners Manual U.S. Patent #6,742,558 Please read carefully! Tools needed for assembly: Phillips screwdriver Tools needed for use: 9/16" socket & wrench...
  • Page 2 Parts List: Additional parts not shown in parts drawings - refer to photos in manual: Qty Part# Description Qty PN Description Qty Part# Description MF040 10-24 x 3/4" screw 1pr 1430CX Vertical Supports MF015 1/4-20 x 1" screw 1430B or 1430B1 Router Block 1430P Router Plate Hardware Package (1430H): Hdw.
  • Page 3 Attach the Router Block (1430B or 1430B1) to the Vertical Install Router Block Support assembly using four 1-1/8" barrel nuts (5791B) and four 1/4-20 x 1" screws (MF015). Lay the Router Block on its side. Insert the bar- Handle in Router Block Fig.
  • Page 4 Nut. Check all screws, especially after initial use, to insure they are tight. If you are having trouble holding a bit height setting, tighten the four locknuts a small amount. See fig. 9. ©Copyright WOODHAVEN INC. 8/4/04 (800) 344-6657 or WWW.WOODHAVEN.COM Fig. 11...

This manual is also suitable for:

Ez lift 1430
