4. SPECIFICATIONS

High Voltage Power Supply
Input Power
Output Voltage
Dimensions
Weight
Operating Temp
Enclosure
High Voltage Connectors
Replacement Fuse
Static Neutralizing Bar
Nominal Bar Length
Profile Dimensions
Weight
Operating Temp
Humidity
Enclosure
HV Conduit
Emitter Material
Emitter Spacing
Operating Distance
Installation Hardware
I Q Power™ B PS
24 VDC, 1.5A from AC adapter
BPS Basic Power Supply +/-7 kV "Speed Bar"; +/-9 kV "Hybrid Bar";
+/-12 kV "Distance Bar"
202L x 123W x 106H mm [7.95"L x 4.85"W x 4.17"H]
1.94 kg [4.28 lb]
43°C [110°F] max
Aluminum, blue polyester powder coated
2 proprietary IQ Power™ plug-in outlets
250V, 5A, Type - 3AG, Time Delay
301 to 3961 mm Overall Length [11.8" to 156"]
210 to 3870 mm Effective Length [8.27" to 152"]
26W x 49H mm [1.00"W x 1.93"H]
1.8 g/mm [0.10 lb/in)
80°C [176°F] max
70% RH max, no dewing permissible
Glass-fiber-reinforced polyester
Flexible non-metallic, black
Proprietary alloy specially selected to extend life
Speed Bar – 30 mm [1.18"]; Hybrid Bar – 90 mm [3.54"]; Distance
Bar – 180 mm [7.09"]
Speed Bar – 50-230 mm [2" to 9"]; Hybrid Bar – 150-460 mm [6" to
18"]; Distance Bar – 300-760 mm [12" to 30"]
Plastic mounting brackets, metal perforated strips and stainless steel
hardware (screws, washers, nuts).
