Initial Considerations - ITW Simco-Ion IQ Power Installation And Operating Instructions Manual

Static neutralizing system with bps power supply

Hide thumbs Also See for Simco-Ion IQ Power:

Table of Contents

Remote On/Off

Normally Off

Normally On

Disabled

Opto High = Unit ON

Opto High = Unit OFF

Opto Low = Unit OFF

Opto Low = Unit ON

Figure 11. Jumper Position at J3 for Remote Control Operation

Initial Considerations

Installation starts with mounting of the static neutralizing bar. Static bars are typically

installed just ahead of where problems due to static are occurring. The power supply is

installed in a convenient location within reach of the static bar high voltage cable and

visible to the machine operator. Communication modules (where used) may be installed at

any convenient location and connected to the system using the modular low voltage cable.

I Q Power™ B PS

5 20 11 97 Re v. D
