to IQ Power
Static Bar
IQ Power Static Bar
Figure 4. IQ Power™ Connections (Bar and Power Supply)
I Q Power™ B PS
17.8mm [0.7"] Speed Bar
25.4mm [1.0"] Hybrid Bar
33.0mm [1.3"] Distance Bar
Captive Screws
Figure 3. IQ Power™ High Voltage Connector
High Voltage Cable
High Voltage Connector
IQ Power BPS
7
Bar Type
Sense Pin
High Voltage
Connectors
Line Cord
Power In Connector
24 VDC
AC Adapter
Ground Connection
5 20 11 97 Re v. D
